Ohlins / オーリンズ STX 46 Street （ストリート）ショックアブソーバー BM 496 | BM 496

Article Number : BM 496

Technical Data
Length : 374 +7mm/-5mm mm
Stroke : 52,5 mm
Rate N/mm : 160 N/mm
Position : rear
Mounted spring : 01092-64
Packaging unit : piece

Type Code : S46PR1C1LB
Single tube
S
Single tube
Piston diameter
46
Piston diameter: 46 mm
Öhlins Motorcycle type P
P
Monotube high pressure gas type of shock absorber with external “piggy back” reservoir.
Öhlins Motorcycle R1 rebound damping adjuster
R1
Adjustable rebound damping on single tube shocks. Adjuster wheel above the end eye.
Öhlins Motorcycle S36C1 compression damping adjuster
C1
Adjustable compression damping. Adjuster wheel or slot on the reservoir.
Öhlins Motorcycle L
L
Adjustable length.
Öhlins Motorcycle B
B
Integrated hydraulic spring preload adjuster. Adjuster wheel or hexagon on the adjuster.
